Migatronic Omega Yard 300 MIG & Stick Welder

Master Any Welding Challenge with the Migatronic Omega Yard 300 MIG & Stick Welder
Migatronic Omega Yard 300 MIG: Unleash superior welding performance and conquer demanding projects with the Migatronic Omega Yard 300 MIG & Stick Welder. This industrial-grade machine is meticulously engineered to excel in harsh environments, delivering exceptional results for professional welders, fabrication shops, and shipyard operations.
Built to Endure, Engineered to Excel
The Omega Yard 300 isn’t your average MIG & Stick welder. Its robust, impact-resistant cabinet and highly insulated electronics provide unwavering reliability, withstanding dust, moisture, and extreme temperatures with ease. The impressive high duty cycle ensures continuous welding operation, minimising downtime and maximising productivity.
Unmatched Versatility and Control
The Omega Yard 300 empowers you to tackle a wide range of welding applications. Effortlessly weld solid and cored wires, as well as Innershield wires (without gas), with diameters up to 1.2mm on 5kg spools. Choose from three user-friendly control panel options: Basic for precise parameter adjustments, Synergic for a multitude of pre-programmed options, and Pulse for the ultimate control and finesse in creating high-quality welds.

Features

Three-phase MIG/MAG and MMA inverter technology for exceptional power and performance
Durable construction withstands harsh environments and demanding use
High duty cycle for extended welding periods without overheating
Choice of control panels: Basic, Synergic, or Pulse
Stable wire feeding: Tacho control and four-roll wire-feed system ensure consistent wire delivery
IGC® Intelligent Gas Control for optimal gas flow and weld quality (available on select models)
Multi-process capability: MIG/MAG, Stick (MMA), and optional pulse welding functionality
Suitable for a wide range of materials: Steel, stainless steel, and aluminium (proper filler metals required)
User-friendly interface: Easy to operate for both experienced and novice welders

Applications

Structural steel fabrication
Shipbuilding
Offshore construction
Heavy machinery manufacturing
Pipeline construction
Bridge construction
Automotive manufacturing

What’s In The Box

Migatronic Omega Yard 300 Inverter
8.5m mains supply cable
ML 300 TWIST 3m torch
3m earth cable with clamp
1.7m diffusion-slow gas hose
4-wheel wire drive rolls and handle

Ordering

Part No.
Description

79541747
Omega 300 Yard Basic

79541749
Omega 300 Yard Synergic

79541752
Omega 300 Yard Pulse

Specifications

300
300 BOOST (3 × 208 V – 3 × 230 V)
300 BOOST (3 × 400 V – 3 × 440 V)

Current range
15-300 A
15-300 A
15-300 A

Mains voltage +/- 15 %
3 × 400 V
–
–

Mains voltage +/-10%
–
3 × 208 V/3 × 230 V
3 × 400 V/3 × 440 V

Fuse type C
16 A
20 A
16 A

Duty cycle 100 %/40 °C (MIG)
220 A/25.0 V
175 A/22.8 V
220 A/25.0 V

Duty cycle 60 %/40 °C (MIG)
240 A/26.0 V
200 A/24.0 V
240 A/26.0 V

Duty cycle max./40 °C (MIG)
300 A/25 %/29.0 V
300 A/20 %/29.0 V
300 A/20 %/29.0 V

Duty cycle 100 %/20 °C (MIG)
300 A/29 V
200 A/24 V
290 A/28.5 V

Duty cycle max./20 °C (MIG)
300 A/29 V
300 A/20 %/29.0 V
300 A/75 %/29.0 V

Duty cycle 100 %/40 °C (MMA)
220 A/28.8 V
140 A/25.6 V
215 A/28.6 V

Duty cycle 60 %/40 °C (MMA)
–
170 A/26.8 V
220 A/28.8 V

Duty cycle max./40 °C (MMA)
250 A/40 %/30.0 V
250 A/22 %/30.0 V
250 A/35 %/30.0 V

Duty cycle 100 %/20 °C (MMA)
250 A/30 V
185 A/27 V
250 A/30.0 V

Duty cycle max./20 °C (MMA)
–
250 A/30 %/30.0 V
250 A/100 %/30.0 V

Open circuit voltage
50-55 V
60 V
60 V

Protection class
IP 23S
IP 23S
IP 23S

Standard
EN/IEC60974 -1. – 5. -10.
EN/IEC60974 -1. – 5. -10.
EN/IEC60974 -1. – 5. -10.

Minimum generator size
16 kVA
17 kVA
16 kVA

Weight
17 kg
20 kg
20 kg

Application class
S/CE
S/CE
S/CE

Dimensions (H × W × L)
455 mm × 222 mm × 638 mm
455 mm × 222 mm × 638 mm
455 mm × 222 mm × 638

Resources
Brochure
Instruction Manual
Spare Parts List
Case Study
Manufacturer’s Product Page

The Migatronic Omega Yard 300 MIG & Stick Welder is an investment in your welding proficiency and project success. Order yours today or book a demo to learn more about this exceptional machine and explore our comprehensive selection of welding supplies. With the right tools and expertise, you can achieve remarkable results.
